bus.gal-api

Python API wrapper for the galician public transport which uses the associated app’s API to get the inforamtion about buses, your card and your user account.

Reverse engineering

#

I used mitmproxy first, to get the basic HTTPS requests the app made. The app has certificate pinning, so I circumvented that on a rooted phone with frida and github.com/httptoolkit/frida-interception-and-unpinning.

This was enough to get all the routing and cards functionality working (the simple requests), but when I decided to implement the logic for the QR codes used to get on the bus I had to inspect the decompiled code of the application using JADX to understand how the QR code was generated.

Turns out this was a pretty insecure thing (which I reported as soon as I found out), where the app always logs in as an administrator with a hardcoded username and password; when it generates a QR the servers returns some data for the code, but the most important one is an integer that represents an index in a hardcoded array in the app code which contains a list of keys (it calls them “public keys” in the code, which does not make sense in DES) used to encrypt/sign the date included in the QR using DES ECB, the rest of the data is just encoded with different methods, but no encryption.

So yeah, you could do a lot of nasty things with this, the app was very poorly designed security-wise. Check the python code on the GitHub repo if you want to learn more (I’m not responsible of the use you make of this information, all of this issued have been reported to the app maintainers several years ago from this being written and are laid out here for educational purposes).

📜 Documentation

#

Documentation can be found here. There are two main submodules: busGal_api.transport and busGal_api.accounts, the first one has all the functions related to transportation and the second one allows you to manage cards and accounts, as the name implies.

👀 Stuff you can do

#

This is just a simple command-line “client” which shows the transport submodule in action by showing a simple timetable for the buses of the trip you specify:

from busGal_api import transport as api
from datetime import date, datetime

NUM_RESULTS=8

def stop_search_menu(prompt):
    query = input(prompt)
    results = api.stops.search_stops(query=query, num_results=NUM_RESULTS)

    for i, result in enumerate(results):
        print(f"{i} -- {result.name}")

    selection = int(input("Which number do you want? >>> "))

    return results[selection]

origin = stop_search_menu("Where do you want to start your trip? >>> ")
destination = stop_search_menu("And where do you want to go? >>> ")

date_str = input("And when? (dd-mm-yy) (defaults to today) >>> ")
date = datetime.strptime(date_str, "%d-%m-%Y") if date_str else date.today()

expeditions = api.expeditions.search_expeditions(origin=origin, destination=destination, date=date)

if expeditions == None:
    print("No results")
    exit()

print("\nORIGIN  |  DEPARTURE  |  DESTINATION  |  ARRIVAL\n")
for expedition in expeditions:
    print(expedition)

This one shows your cards and makes you rename them:

from busGal_api import accounts as api

print("Please login to continue")
account=api.Account(input("Email: "), input("Password: "))

print("Here are your cards. You are going to rename each of them")
cards=account.get_cards()
for card in cards:
    print(card)
    card.rename(input("New name: "))

Now, for XenteNovaQr, here is the most typical use case, generating a QR to pay in the bus:

from busGal_api import accounts as api
import qrcode
from time import sleep

print("Please login to continue")
tpgal_account = api.Account(input("Email: "), input("Password: "))
xn_account = api.xentenovaqr.Account(tpgal_account.user_id) # This will only work if you have already registered for this service. You do so on the app or using the function for that purpose (not tested nor recommended)

qr_entity = xn_account.create_qr()
qr = qrcode.QRCode()
while True:
    qr.add_data(qr_entity.qr_string)
    print("Scan this code fast, it will refresh in 30s!")
    qr.print_ascii()
    sleep(30)
    qr_entity.refresh_qr_string() # This is done offline
    qr.clear()
